Step 01
Survey and measure
Look at every surface: material, condition, edges, hardware, curves and how people use it.
SpecNote damage, swelling, moisture and texture
Architectural film applications
Elevators, doors and desks. Refaced where they stand.
Architectural film can refinish elevator interiors, doors, reception desks and millwork without tearing them out. Here is what can be wrapped, what should not be, and how the work runs, based on 3M's own guides.
Start here
Two things people mean by elevator wrap
One is a printed graphic on the elevator doors, usually a brand message or an event. The other is architectural film, such as 3M DI-NOC, that refinishes the cab and doors in a wood, metal or stone look for years. This page covers the second, along with doors, desks and millwork.
Both put film inside an elevator, so both raise the same first question: who signs off. That comes before finish samples.
- Refacing keeps the door, panel or desk in place and changes the surface.
- Film needs a sound, smooth, sealed surface. It does not repair a damaged one.
- Vertical surfaces are the sweet spot. Tops and other horizontal surfaces need a tougher film or a different material.
Applications
What can be wrapped
Chips show whether 3M names the use, or whether it is a reasonable fit that needs the substrate confirmed first.
- Code sign-off first
Elevators
Cab interiors
Cab walls, handrail returns, kickplates and reveal trim over existing metal, wood or laminate. 3M names elevators as a use for its Abrasion Resistant series.
- Code sign-off first
Elevators
Doors and entrance frames
Door panels and the frames around them, inside the car and in the lobby. Cladding that faces the car interior has fire requirements under elevator codes.
- Named by 3M
Doors
Interior doors and frames
3M lists doors as a core use. Flat-slab doors wrap more cleanly than doors with deep recessed panels. Edges get primer and extra film to wrap.
- Confirm substrate
Desks
Reception desks
Front and side panels are the natural fit. Desk tops take daily wear, so they need the Abrasion Resistant series or a different material.
- Named by 3M
Millwork
Cabinetry and built-ins
Cabinet faces, built-ins and wood panels refinished in place. A 3M hospital case study refaced one unit's patient doors and cabinets to a light-wood look.
- Named by 3M
Structure
Columns
Square and round columns in stone, wood or metal looks. 3M sets a warmer minimum surface temperature for curves: 61 F for simple curves.
- Walls yes, ceilings ask
Surfaces
Walls and ceilings
Walls work after a Level 5 drywall finish and sealing. Ceilings are a harder call: 3M says durability drops significantly when film sits more than 10 degrees off vertical.
- Confirm substrate
Retail
Store fixtures
Vertical faces of fixtures, display walls and cash wraps. Check that the substrate is smooth and sealed, and keep standard film off high-wear tops.
Ask first
Elevators need sign-off before film goes on
Elevator interiors are regulated. One example: a 2022 bulletin from Technical Safety BC in Canada says door cladding facing the car interior must meet the ASME/CSA B44 elevator code (2016 edition) and an ASTM E84 flame spread of 0 to 75 and smoke developed of 0 to 450, with documents filed with the alteration permit. Washington rules may differ. The building's licensed elevator contractor and permit holder need to approve the plan before any film goes on a cab.
Ask first
Labeled fire doors
3M lists Intertek fire door testing among its industry-specific tests and says to consult 3M Technical Service. As general practice, do not cover a labeled fire door without written approval from 3M and the local fire authority.
Reface or replace, item by item
Qualitative only. No independent cost study was found, and every building is different.
| Item | Refacing with film | Replacement | Watch for |
|---|---|---|---|
| Elevator cab | An elevator contractor reports film renovations can fit an overnight or weekend window. | Demolition, fabrication and reinstall while the car is out of service. | Code approval; Abrasion Resistant film for high-touch panels |
| Doors and frames | Door stays hung. Surface, edges and frame are refinished. | New door, hardware fit-up and finishing. | Labeled fire doors; deep recessed panels; swollen or delaminated doors |
| Reception desk | Fronts and sides refinished where the desk stands. | New desk built and installed. | Tops and edges that take daily wear |
| Cabinets and millwork | Faces refinished; boxes and hardware stay. | Tear-out and new casework. | Water-damaged or swollen cores |
Sources: Engineered Group elevator cab renovation page (contractor, secondary); 3M DI-NOC product page and installation guide; 3M HealthPartners case study (2017).
Process
How a refacing job runs
This is the sequence 3M's installation and prep guides describe, in plain terms.
Limits
What not to wrap
Film copies a surface. It does not fix what is under it, and it has limits on where it holds up.
- Doors, cabinets or panels that are damaged, swollen, delaminated or water-damaged.
- Countertops, desk tops and table tops with standard film. 3M points to its Abrasion Resistant series for horizontal high-wear areas.
- Floors.
- Compound curves, which 3M says the film will not conform around.
- Elevator surfaces without the elevator contractor's approval.
- Labeled fire doors without written approval from 3M and the local fire authority.
- Showers, steam rooms and spots where condensation forms.
- Exterior doors with standard film. 3M's EXR series covers exterior doors and window frames.
- Surfaces that get cleaned with acetone, methyl ethyl ketone, toluene or ethyl acetate.
Hiring an installer
Questions to ask a 3M DI-NOC installer
Whoever you hire, these questions separate a careful installer from a fast one. Each answer should point back to a 3M document.
- Will you run 3M's adhesion test on my actual doors, panels or walls before you quote?
- Which adhesion promoter will you use on edges and seams: Tape Primer 94, VHB Tape Universal Primer UV or WP-2000?
- Which series fits this surface? For elevators and high-touch panels, is the Abrasion Resistant series a better fit?
- What is the fire rating for the exact design you are quoting, and will you give me the data sheet?
- Which warranty applies, from which data sheet revision, and what do I need to do to keep it?
- Where will the seams fall, and how will you handle hardware, hinges and door edges?
- Has the elevator contractor or building manager approved the plan?
- What happens at removal? 3M warns it may damage the surface underneath.
FAQ
Frequently asked questions
What is an elevator wrap?
Either a printed graphic on elevator doors, or architectural film that refinishes the cab and doors in a wood, metal or stone look. 3M names elevators as a use for its Abrasion Resistant DI-NOC series.
Can you wrap elevator doors?
Film can go on elevator door panels and frames, but door cladding facing the car interior has fire requirements under elevator codes. The building's licensed elevator contractor and permit holder need to approve it first.
Is elevator wrap film fire rated?
3M's US data sheets list most DI-NOC products, and its Abrasion Resistant series, as Class A under ASTM E84 for interior use as defined by NFPA 101. Confirm the rating for the exact design, and what your elevator code requires, before you order.
What is door wrap film?
A self-adhesive architectural film applied over an existing door and frame to change its finish. 3M lists doors as a core use for DI-NOC. Flat-slab doors give the cleanest result.
Can you wrap a fire-rated door?
Ask first. 3M lists Intertek fire door testing and says to consult 3M Technical Service. As general practice, a labeled fire door should not be covered without written approval from 3M and the local fire authority.
Can you wrap a reception desk top?
Not with standard film. 3M says durability drops on horizontal surfaces and points to its Abrasion Resistant series for high-wear areas. The desk front and sides are the usual fit.
How long does architectural film last on doors?
3M gives an expected life of 12 years for indoor vertical applications, typical and not warranted. Its US data sheet lists a 10-year warranty for interior commercial use, with 5 years for a few series.
Who can I call about refacing in the Seattle area?
Ask Ardor Printing about architectural film refacing at (425) 629-0796. Ardor installs wall wraps and window film across Greater Seattle with its own crew and can talk through your doors, desks or elevator project.
Sources
- [1] 3M DI-NOC Architectural Finishes Technical Data Sheet, Rev S (US), March 2024 (opens in a new tab)
- [2] 3M DI-NOC Architectural Finishes Technical Data Sheet, Rev T, June 2024 (opens in a new tab)
- [3] 3M DI-NOC Installation Guide, Rev M (opens in a new tab)
- [4] 3M DI-NOC Drywall Preparation and Installation Guidelines, Rev C, January 2022 (opens in a new tab)
- [5] 3M DI-NOC EXR Series Product Bulletin, Rev L, October 2025 (opens in a new tab)
- [6] 3M DI-NOC Abrasion Resistant (AR) Series Technical Data Sheet, Rev C, October 2020 (opens in a new tab)
- [7] 3M DI-NOC Architectural Finishes product page (EU) (opens in a new tab)
- [8] 3M case study: HealthPartners Regions Hospital (2017) (opens in a new tab)
- [9] Surface Supply, Guide to 3M DI-NOC (retailer blog, secondary) (opens in a new tab)
- [10] Engineered Group, Elevator cab renovation (contractor page, secondary) (opens in a new tab)
- [11] Technical Safety BC, Information Bulletin IB-ED 2022-02, Elevator Door Cladding (Oct 12, 2022) (opens in a new tab)
